Sliding sledge A HV 100-150 50x5
457 mm unlined hot-dip galv.
| Part no. | 142afa0457 |
| EAN/GTIN | 4250928462633 |
| Packing unit | 1 pcs |
| Quantity unit | pcs |
| Weight | 18,17 kg/pc |
| Product group | 14-143 |
| Price unit | 1 |
Your price
|
|
Product filter:
| Specification | Double-L-support |
| Closure | Nut / closure screw |
| Material | Steel |
| Material type | S235 |
| Surface | hot-dip galvanized |
| Sound insulation lining | unlined |
| Safety factor | 1,54 |
| Closure screw | M12 |
| Outer pipe diameter | 457 mm |
| Material thickness | 8 mm |
| Width pipe clamp strap | 50 mm |
| Width substructure | 341 mm |
| Length of substructure | 270 mm |
| load FX | 7,37 kN |
| load FY | 20 kN |
| load FZ hanging | 15,15 kN |
| load FZ standing | 30,31 kN |
| Thickness clamp strap | 5 mm |
| min. height base | 94 mm |
| max. height base | 150 mm |
